TOPDON Battery Booster V4500 Plus

Operating voltage:
  • 12 [V]
Starting current:
  • 4500 [A]
Capacity
  • 32000 [mAh]
Dimensions (L x W x H):
  • 320 X 310 X 175 [mm]
Weight:
  • 4.40 [kg]
Warranty:
  • 12 months

Features

  • Power Up Any Heavy-Duty Engine - The TOPDON V4500 Plus Jump Starter is built for the demands of high-displacement vehicles, from semi-trucks to heavy trailers. Delivering a peak current of 4500A, it handles 12V systems across both gasoline and diesel engines with displacements reaching up to 16 liters — making it one of the most capable portable starters on the market.
  • Know Your Battery's Health - The V4500 Plus goes beyond emergency starting. Connect it to the companion app and it transforms into a full-featured battery diagnostic tool, giving you the ability to run detailed battery health checks before ever thinking about a replacement. This dual functionality puts the power of assessment in your hands, helping you skip unnecessary trips to the shop and avoid replacing a battery that still has life left in it. Stay one step ahead of potential problems and keep unexpected breakdowns off the road for good.
  • Lightning-Fast Charging - The V4500 Plus takes rapid charging to a new level with its dual-direction PD100W fast charging port. A full recharge from 0 to 100% takes just 90 minutes, meaning you're never left waiting when it matters most. Need to top up your phone on the go? A full charge takes as little as 20 minutes, keeping you connected no matter the situation.
  • Built to Push Through the Toughest Starts - When a stubborn battery refuses to cooperate, the V4500 Plus Boost mode steps in where others fall short. Unlike conventional boost modes that cut out after just a few seconds, this one sustains current output for a full three minutes — giving you multiple start attempts back to back. Whether you're dealing with freezing temperatures, a high-displacement engine, or a deeply drained battery, it keeps pushing until the job is done.
  • Power On the Move - With a 120Wh capacity, the V4500 Plus doubles as a capable portable power bank wherever the road takes you. Dual USB QC 3.0 fast charging ports and a 12V DC output keep your essential onboard gear — from dash cams to portable refrigerators — running reliably without skipping a beat.
  • Safety You Can Count On, Every Time - The V4500 Plus is engineered with protection in mind from the outside in. Its IP65-rated enclosure seals out dust and resists water damage, while 100% heavy-duty copper cables deliver consistent conductivity and long-lasting durability. On top of that, 10 intelligent safety technologies work in the background to guard against overload, overheating, and voltage irregularities — actively monitoring conditions to protect both the device and your equipment, and extending the lifespan of everything connected to it.

Light Up the Dark When It Matters - Whether you're making roadside repairs, navigating a campsite, or managing an emergency, the V4500 Plus has you covered with 15 ultra-bright LEDs delivering up to 500 lumens of light, backed by 6 red warning indicators. On a full charge, the light can run for an impressive 800 hours continuously — so you'll never be left in the dark.

Technical Features

  • Starting Current (Peak): 4500A
  • Capacity (mAh): 32000mAh / 120Wh
  • Type-C Input / Output: 100W (5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/3A, 20V/5A)
  • Type-C Input / Output: 100W (5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/3A, 20V/5A)
  • USB1 Output: QC18W 12V/1.5A, 9V/2A, 5V/3A
  • USB2 Output: QC18W 12V/1.5A, 9V/2A, 5V/3A
  • DC output: up to 16.8V / 10A
  • Operating Temperature (°C): -10°C ~ +55°C
  • Storage Temperature (°C): -20°C ~ +55°C
  • Gasoline Engine Jump-Start Capacity (CC): Up to 16L
  • Diesel Engine Jump-Start Capacity (CC): Up to 16L
  • Total Length (mm): 320
  • Total Width (mm): 310
  • Total Height (mm): 175
  • Weight (kg): 4.40

Packing List

  • V4500 Plus
  • Battery Test Clamps
  • PD45W Charger Adapter
  • DC Adapter
  • PD100W Cable
  • User Manual
  • Packing Box
  • Cars
  • Trucks
  • Tractors
  • Boats
  • SUV
  • Semi-trailers
  • Trailers
  • Off-road vehicles
